Konec Dual Illumination Turret PoE Camera
Konec Dual Illumination Turret PoE Camera
Konec Dual Illumination Turret PoE Camera
Improve your home security with the Konec security camera range, offering visibility of your exterior property alongside a two-way talk feature. The diverse designs within the range complement your exterior layout, ensuring both reassurance and peace of mind.
Improve your home security with the Konec security camera range, offering visibility of your exterior property alongside a two-way talk feature. The diverse designs within the range complement your exterior layout, ensuring both reassurance and peace of mind.
Improve your home security with the Konec security camera range, offering visibility of your exterior property alongside a two-way talk feature. The diverse designs within the range complement your exterior layout, ensuring both reassurance and peace of mind.
Model:
KSN-IPR8050-CQAS-B-5MP
SKU:
KNC00073
Certifications:
RCM
Colours:
White
Connection Protocol:
Ethernet
Model:
KSN-IPR8050-CQAS-B-5MP
SKU:
KNC00073
Certifications:
RCM
Colours:
White
Connection Protocol:
Ethernet
More
Model:
KSN-IPR8050-CQAS-B-5MP
SKU:
KNC00073
Certifications:
RCM
Colours:
White
Connection Protocol:
Ethernet
General Specifications
General Specifications
General Specifications
Motorised Zoom
Full Colour Night Vision
PoE Power
Motorised Zoom
Full Colour Night Vision
PoE Power
Motorised Zoom
Full Colour Night Vision
PoE Power
Motorised Zoom
Full Colour Night Vision
PoE Power
Product Specs
Product Specs
Product Specs
Input Voltage
• DC 12V (-15%~+25%)• PoE (IEEE 802.3af)
Operating Temperature
• -40°C ~ 55°C
Operating Humidity
• 5%-90%RH (Non-condensing)
IP Rating
• IP66
Lens Type
• Fixed focus
Iris
• Fixed Iris
Focal Length
• 4 mm
F Number
• F1.6
Camera Viewing Angle
• Pan
Image Sensor
• 1/2.8" Progressive Scan CMOS
Camera Resolution
• 5MP (2592x1944)
Electronic Shutter
• Auto/Manual• 1/5 ~ 1/20,000s
Min. illumination
• Color
Day & Night
• IR cut filter
IR Distance
• IR distance up to 40m• Warm light distance up to 30m
Illumination On/Off Control
• Auto/Manual
Network
• 1 Ethernet (10/100 Base-T) RJ-45 Connector
Audio Interface
• 1ch Input• 1ch Output
Built-in Microphone
• Yes
Built-in Speaker
• Yes
Alarm Interface
• 1ch Input• 1ch Output
Reset Button
• Support
SD Card Slot
• Built-in, up to 256GB
