General Specifications

General Specifications

General Specifications

Full Colour Night Vision

Full Colour Night Vision

Activity Zones

Activity Zones

Motorised Zoom

Motorised Zoom

PoE Power

PoE Power

Remote Control

Remote Control

Full Colour Night Vision

Full Colour Night Vision

Activity Zones

Activity Zones

Motorised Zoom

Motorised Zoom

PoE Power

PoE Power

Remote Control

Remote Control

Full Colour Night Vision

Full Colour Night Vision

Activity Zones

Activity Zones

Motorised Zoom

Motorised Zoom

PoE Power

PoE Power

Remote Control

Remote Control

Full Colour Night Vision

Full Colour Night Vision

Activity Zones

Activity Zones

Motorised Zoom

Motorised Zoom

PoE Power

PoE Power

Remote Control

Remote Control

Product Specs

Product Specs

Product Specs

  • Input Voltage

    DC12V(-15%~+25%) POE (IEEE 802.3af)

  • Power Consumption

    Max. 10.5W

  • Operating Temperature

    -40°C ~ 55°C

  • Operating Humidity

    1% ~ 90% RH (Non-Condensing)

  • IP Rating

    IP66

  • Casing Material

    Metal

  • Image Sensor

    1/2.8" Progressive Scan CMOS

  • Max. Resolution

    5MP (2592 × 1944)

  • Iris

    Fixed Iris

  • Focal Length

    2.7 ~ 13.5 mm

  • F Number

    F1.6

  • Camera Viewing Angle

    H

  • Camera Resolution

    5MP (2592*1944)

  • Installation Angles

    Tilt 0˚ ~ 90˚ Rotation or Pan 0˚ ~ 360˚

  • Day & Night

    IR cut filter

  • Electronic Shutter

    Auto/Manual, 1/5 ~ 1/20,000s

  • Min. illumination

    Color

  • Input Voltage

    DC12V(-15%~+25%) POE (IEEE 802.3af)

  • Power Consumption

    Max. 10.5W

  • Operating Temperature

    -40°C ~ 55°C

  • Operating Humidity

    1% ~ 90% RH (Non-Condensing)

  • IP Rating

    IP66

  • Casing Material

    Metal

  • Image Sensor

    1/2.8" Progressive Scan CMOS

  • Max. Resolution

    5MP (2592 × 1944)

  • Iris

    Fixed Iris

  • Focal Length

    2.7 ~ 13.5 mm

  • F Number

    F1.6

  • Camera Viewing Angle

    H

  • Camera Resolution

    5MP (2592*1944)

  • Installation Angles

    Tilt 0˚ ~ 90˚ Rotation or Pan 0˚ ~ 360˚

  • Day & Night

    IR cut filter

  • Electronic Shutter

    Auto/Manual, 1/5 ~ 1/20,000s

  • Min. illumination

    Color

  • Input Voltage

    DC12V(-15%~+25%) POE (IEEE 802.3af)

  • Power Consumption

    Max. 10.5W

  • Operating Temperature

    -40°C ~ 55°C

  • Operating Humidity

    1% ~ 90% RH (Non-Condensing)

  • IP Rating

    IP66

  • Casing Material

    Metal

  • Image Sensor

    1/2.8" Progressive Scan CMOS

  • Max. Resolution

    5MP (2592 × 1944)

  • Iris

    Fixed Iris

  • Focal Length

    2.7 ~ 13.5 mm

  • F Number

    F1.6

  • Camera Viewing Angle

    H

  • Camera Resolution

    5MP (2592*1944)

  • Installation Angles

    Tilt 0˚ ~ 90˚ Rotation or Pan 0˚ ~ 360˚

  • Day & Night

    IR cut filter

  • Electronic Shutter

    Auto/Manual, 1/5 ~ 1/20,000s

  • Min. illumination

    Color
